Genesis Centrifuge is the most commonly used centrifuge for blood cell or stem cell related separations.
Since EDM Centrifuge adopted soft spinning ,quiet
operation, and many other advanced functions,
any kind of separation will be performed in excellent
condition to give the best result.
Application areas of EDM Centrifuge
General laboratory
Cellular materials/Blood/Urine/Sperm etc.
Clinical Application
PRP, PRF, Lipid cell separation,
stem cell isolation
Specification of Genesis Centrifuge
|
MODEL |
EDM - S450 |
EDM - S 424 |
||
|
Max. RPM/RCF |
Fixed Angle |
4,000 / 2,700 xg |
Fixed Angle |
4,000 / 2,025 xg |
|
Swing Out |
4,000 / 2,774 xg |
|||
|
Max. Capacity |
Fixed Angle |
16 x 15 ㎖ |
Fixed Angle |
12 x 15 ㎖ |
|
Swing Out |
4 x 100 ㎖ |
|||
|
Time control |
Timed < 100 min or continuous |
Timed < 60 min or continuous |
||
|
RPM/RCM Conversion |
Yes |
Yes |
||
|
Noise level(dB) |
≤ 50 |
≤ 55 |
||
|
Acc/Dec(sec) |
≤ 18 / ≤ 18 |
≤ 15 / ≤ 15 |
||
|
SOFT Start/Stop |
Yes |
Yes |
||
|
Imbalance cut off |
Yes |
Yes |
||
|
Lid drop protection |
Yes |
Yes |
||
|
Power supply (V/Hz) |
220 / 50~60 (110V Optional) |
220 / 50~60 (110V Optional) |
||
|
Power requirement (VA) |
250 w |
150 w |
||
|
Dimension (W x D x H, mm) |
325 x 450 x 250 |
325 x 450 x 250 |
||
|
Weight without rotor (Kg) |
18.5 |
15.5 |
||
|
CE Mark |
Yes |
Yes |
||
|
Cat. No. |
EL-3712 |
EL-3711 |
||
